TOP-PCVIEW1930HA Product Guide.
TOP-PCVIEW1930HA
- Certification
-
-
Intel® Core-i5 8365UE CPU
Intel® Core-i5 8365UE CPU
-
HMI / PC Compatibility
Mutual compatibility between TOP project
and SCADA project
Same panel cut as TOP series
-
Large Capacity SSD
2.5 inch SSD 256GB default supply
-
Ethernet 2 Channels
2 independent ethernet network channels
-
Excellent Fanless Structure
Highly-efficient heat sink installed
Fit to quiet location, no need for fan maintenance
-
USB 5 Ports
USB 3.1 4 ports, USB 2.0 1 ports
-
Aluminum Frame
Strong durability and refined design of aluminum body
-
Front IP65 Compatible
Safe use in wet and dusty environment
-
5-wired Touch Panel
5-wired analog touch panel
-
16M Full Color
Bright and clean full color, vector image library
- Display
- Display Type: 18.5" TFT Color
Color: 16M Colors
Resolution: 1366 x 768
- System
- Processor Number: Intel® Core-i5 8365UE
CPU Speed: 1.6GHz@4.1GHz(4C/8T)
Memory: DDR4 SO-DIMM 8GB
Storage: 2.5" SSD 256GB
- Serial COM1, COM2
- RS-232C, RS-422/485 Asynchronous(Selected BIOS)
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 1, 3.5mm 5P x 1
- Serial COM3, COM4
- RS-232C Asynchronous
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 2
- Ethernet
- IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.ab, 10BaseT/100BaseT/1000BaseT
Connector: RJ-45 x 2
- USB Host
- USB 2.0 Compatible, Output 5Vdc/0.5A
Connector: USB Type Micro B x 1
USB 3.1 Compatible, Output 5Vdc/0.9A
Connector: USB Type A x 4
- HDMI Out
- HDMI v1.4, HDMI output, Max. Resolution: 4096 x 2160 at 24Hz
Connector: HDMI x 1
- DP Out
- DP v1.2, HDMI output, Max. Resolution: 4096 x 2306@60Hz
Connector: DP x 1
- Audio
- High Definition Audio(HD), Line-in, Line-out, Mic-in
- Structure
- Panel Cut: 479 x 298
Dimension: 497 x 316 x 94.8
Weight: 5.6kg
Case: Metal
