T O P R D 1 5 2 0 X + T O P R P 2 0 D
- 15", Premium model, 1024x768
Surprise with Speed 1.4GHz Quad Core CPU
Firm Exterior, Luxurous Design Aluminum Body
Beautiful Colaboration Detachable Process Unit
Gesture Function 3 Point Sensing Multi Touch
Bright and Clear Full Color LCD
Broad Expanse of Interface Multimedia Functions
- 3 Serial Ports, 2 Ehernet Ports, USB
- Camera, WiFi, Fieldbus, HDMI, Audio, Video
1. Functional
TOPRD1520X
Display |
Display Type![]() ![]() ![]() ![]() |
15' TFT Color |
---|---|---|
Color | 16M Colors | |
Display Area(mm) | 304.1x228.1 | |
Resolution(dot) | 1024x768 | |
Brightness Level | 10 Levels(by software)![]() |
|
Backlight Type![]() |
LED | |
Backlight Life ![]() |
![]() ![]() ![]() ![]() |
|
Touch |
Touch Type | ![]() ![]() |
Resolution(Cell) | 1024x768 | |
Touch Life | 1 million times or more | |
Embedded Device | Front Camera | USB UVC Max. resolution: 640x480![]() ![]() ![]() ![]() ![]() ![]() |
Proximity Sensor | Yes | |
Illumination Sensor | Yes | |
Structure | Panel Cut(㎜) | 355x286 |
External D![]() |
370x301x36.7 | |
Weight(㎏)![]() |
3.58 |
- TOPRP20D
Interface
Serial COM1
RS-232C, RS-422/485 Asynchronous +5Vdc PWR
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 1
Serial COM2
RS-232C, RS-422/485 Asynchronous
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: DSUB 9pin x 1
Serial COM3
RS-485 Asynchronous
Data bit: 7/8 bits, Stop bit: 1/2 bits, Parity bit: None/Odd/Even
Baud rate: 2400~115.2kbps
Connector: 3.5mm 3pin x 1
Ethernet
IEEE802.3i/IEEE802.3u, 10BASE-T/100BASE-TX
Connector: RJ-45 x 2
USB Host
USB 2.0 Compatible, Output 5Vdc/0.5A
Support: USB Storage, USB Barcode Scanner(Standard Keyboard Protocol)
Connector: USB Type A x 2
USB OTG
USB 2.0 Compatible, Output 5Vdc/0.5A, Max 5m
Support: USB Storage, USB Barcode Scanner(Standard Keyboard Protocol)
Connector: USB Micro-B(Front) x 1
SD Card
SD Card Slot x 1, SDHC(MAX 32GB)
Option Modules
EtherCAT, CANopen, CAM32
HDMI Output
HDMI output, Max. Resolution: 1920x1080
Connector: HDMI x 1
Video Input
Decodes NTSC, PAL or SECAM composite video, S-Video
Connector: RCA socket x 1
Audio Output
Stereo output
Connector: 3.5mm Audio socket x 1
Wifi
2.4G: 2.4000GHz~2
.4835GHz
WLAN Standard: IEEE808.11b/g/n
Operation Range Up to 150meters in open space
Security: WEP, TKIP, AES, WPA, WPA2
Printer
Almost USB interface Printers, Roll Printer(EPSON protocol): RS-232C
Memory
& OthersScreen Memory
128MB
Backup Memory
512KB: System buffer(10K Word), Including Alarm/Logging/Recipe
Backup Period
Permanent
Real Time Clock
Built in
Status LED
3 LEDs(Power, Operation, Link) Bui
lt in
Structure
External Dimension(㎜)
201
.6
x147.
6x37.3
Weight(kg)
0.82
2. General
Display + Process Specifications
Power
Input Voltage
24Vdc(20~28Vdc)
Power Consumption
18W or less
Voltage Sag
24Vdc, Within 10㎳
Insulation Resistance
500Vdc, 10㏁
Environment
Operation Temperature(℃)
-10 ~ +50
Storage Temperature(℃)
-20 ~ +60
Operation Humidity(%RH)
0 ~ 90(No Dew)
Atmosphere
No corrosive gas
Vibration Endurance
Amplitude: 10≤F<25㎐(2G) X,Y,Z each direction(for 30 minutes)
Noise Immunity
1000Vp-p(Pulse width 1㎲)
Static Electricity Discharge
Connective discharge from EN61000-4-2: ±4㎸
Shock Endurance
10G X,Y,Z each direction(for 3 times)
Ground Connection
Class 3(100Ω or less)
Protection Classification
IP65(Front)
Certification
CE, KC, UL
Structure
Weight (kg)
4.4
Cooling System
Natural air circulation
Case material
AL(Aluminum)
